LEA Connect 704
The LEA Connect 704 is a four-channel professional smart amplifier designed for small- to medium-scale AV installations. It delivers up to 700 watts per channel and supports both low-impedance (Lo-Z) and high-impedance (Hi-Z) speaker systems, with 70V or 100V operation selectable per channel. Built-in Wi-Fi, Ethernet networking and cloud connectivity enable remote configuration, monitoring and control from a web browser or compatible control platform.
- Four amplifier channels, rated at 700 W per channel.
- Direct Lo-Z and Hi-Z operation, including selectable 70V/100V.
- Built-in Wi-Fi access point, existing Wi-Fi network and Ethernet connectivity.
- LEA Cloud remote monitoring, control and notifications.
- Smart Power Bridge technology for bridging without sacrificing another amplifier channel.
- 96 kHz digital signal processing (DSP).
- Eight-band parametric EQ per channel.
- Input routing matrix, crossover filters and speaker limiters.
- Real-time load monitoring and external I/O for remote on/off and fault monitoring.
- Efficient Class-D amplifier output stage
Hardware details
- Amplifier type: Class-D professional amplifier.
- Channels: 4 independent amplifier channels.
- Power output: 1,500 W per channel.
- Analog inputs: 4 balanced inputs.
- Speaker compatibility: Low-impedance (Lo-Z) and high-impedance (Hi-Z) systems, including 70V/100V operation.
- Network connectivity: Ethernet and built-in Wi-Fi.
- Dante version: Supports Dante audio networking and configurable AES67, depending on the model variant.
- External I/O: Remote power on/off and amplifier-health indication.
- Power supply: Universal switch-mode power supply with power factor correction (PFC).
- Cooling: Variable-speed fan with front-to-rear airflow.
- Rack mounting: 2U rack format.
- Weight: Approximately 11.8 kg
Software and DSP details
- DSP processing: 96 kHz, 32-bit Analog Devices Sigma processor.
- Equalization: 8-band parametric EQ per channel, as specified in the detailed product documentation.
- Input routing: Flexible input-to-output routing with primary/secondary input priority.
- Crossover filters: Linear-phase FIR filters and IIR filters up to 48 dB/octave.
- Output delay: Up to 4 seconds per channel.
- Speaker protection: Adjustable peak-voltage and RMS-voltage limiters.
- Monitoring: Real-time load monitoring and pilot-tone detection.
- Fault protection: DC, VHF, overtemperature, current, AC mains and fan-fault protection.
- Remote control: Browser-based WebUI, third-party API and LEA Cloud.
- Network audio: Dante/AES67 capabilities are specific to the Dante Connect variant, not the standard Network Connect model.
Corporate meeting rooms and conference rooms
Corporate training rooms
Small to medium-sized auditoriums
University classrooms and lecture halls
Corporate town hall spaces
Restaurants
cafeterias and dining areas
Houses of worship
Hotels and hospitality venues
Retail stores and commercial spaces
Multi-zone background music and public-address systems
| Parameter | Value |
|---|---|
| Power at 2 Ω | 350 W/channel |
| Power at 4 Ω | 700 W/channel |
| Power at 8 Ω | 700 W/channel |
| Power at 25 V | 700 W/channel |
| Power at 70V/100V | 700 W/channel |
| THD+N | 0.1%, 20 Hz–20 kHz |
| Frequency response | 20 Hz–20 kHz, ±0.5 dB at 4 Ω, 8 Ω, 70V and 100V |
| Signal-to-noise ratio | 105 dB, referenced to 8 Ω |
| Crosstalk | 70 dB, 20 Hz–20 kHz |
| Output delay | 100 ms/channel |
| Rack height | 1U |
| Dimensions | 482 × 362 mm footprint dimensions; 1U height |
| Weight | Approximately 4 kg |
